Drawdown

A drawdown is a fall in value from a previous peak, shown as a percentage. Plain-English definition, how maximum drawdown is measured, and a worked example.

Also called: draw-down, peak-to-trough decline, peak-to-valley drawdown, maximum drawdown

A reservoir with low water exposing its dry, stony shore
“Angram Reservoir during a Dry Summer - geograph.org.uk - 5844790” by Chris Heaton — CC BY-SA 2.0 (edited: cropped, recolored)

Quick answer

A drawdown is a decline in an investment's or account's value from a previous peak, usually expressed as a percentage of that peak. The maximum (or worst peak-to-valley) drawdown is the largest such fall over a period.

What does drawdown mean?#

U.S. commodity-pool regulations define a draw-down as losses experienced by a pool or account over a specified period. They define the worst peak-to-valley draw-down as the greatest cumulative percentage decline in month-end net asset value during any period before the earlier value is equaled or exceeded[1]. Those definitions come from Commodity Futures Trading Commission (CFTC) rules for certain U.S. funds; rules differ by country, but the peak-to-valley idea is used to describe any portfolio.

To calculate a drawdown, divide the current value by the highest value so far and subtract from 1. The deepest result over the period is the maximum drawdown.

What does a drawdown look like with numbers?#

Worked example

An account that rises, falls and recovers

Assumptions: a hypothetical account, values at month-end, no deposits or withdrawals. The account peaks at $12,000, falls to $9,000 and later reaches a new high of $12,500. The maximum drawdown is 25.00%, and getting from $9,000 back to $12,000 needs a 33.33% gain.

StepAccount valuePeak so farDrawdown
Start$10,000$10,0000.00%
New high$12,000$12,0000.00%
Fall$9,000$12,00025.00%
Partial recovery$11,000$12,0008.33%
New high$12,500$12,5000.00%

Figures computed in code from the stated inputs; rounded to the nearest cent or tenth.

How much gain does it take to recover from a drawdown?#

Worked example

The gain needed to get back to the old peak

Assumption: no deposits or withdrawals, so only investment returns can close the gap. The required gain is 1 ÷ (1 − fall) − 1. It grows much faster than the fall itself.

Fall from the peakGain needed to return to the peak
10%11.11%
20%25.00%
25%33.33%
34%51.52%
50%100.00%
89%809.09%

Figures computed in code from the stated inputs; rounded to the nearest cent or tenth.

The last row is not invented: Federal Reserve History records that after the 1929 crash the Dow Jones Industrial Average closed at 41.22 in the summer of 1932, 89 percent below its peak, and did not return to its pre-crash heights until November 1954[2]. The 34% row matches the 2020 example below.

What is a real-world example?#

Researchers at the Federal Reserve Bank of St. Louis wrote that after peaking on Feb. 19, 2020, the S&P 500 dropped to 66% of its peak by March 23 — a drawdown of about 34% — and stood at 115% of that pre-crisis peak a year later[3]. One fast recovery does not predict the next: a future drawdown could take much longer to recover, or might not recover within your time horizon.

Where will you see this term?#

Drawdown figures appear in many fund and portfolio reports, and U.S. commodity-pool rules use the term formally. They complement volatility, which measures how much returns swing rather than how far they fell. For the full picture, including why a 50% fall needs a 100% gain to recover, read volatility and drawdowns explained, and see asset allocation for how the mix you choose sets how deep a fall can be.

How should you read a drawdown figure?#

  • Which values? The CFTC rule measures month-end net asset value[1]; a figure built from daily prices includes the lows between month-ends, so it is at least as deep.
  • Which period? A maximum drawdown over three years and one over twenty are different numbers. Check the start and end dates.
  • Recovered or not? The CFTC definition runs until the earlier value is equaled or exceeded[1]. A drawdown still open has no recovery date yet.
  • Who reports it. U.S. mutual fund prospectuses do not use the word, but must show the highest and lowest quarterly return over the bar-chart period[4], which gives a similar warning.

What mistakes do beginners make?#

  1. Thinking a 50% loss needs a 50% gain

    It needs 100%, as the table shows. The deeper the fall, the larger the climb back.

  2. Confusing drawdown with volatility

    Volatility measures how widely returns swing; drawdown measures how far value fell from a high. An investment can have modest swings and still suffer one long, deep slide. See volatility.

  3. Selling at the low point

    Selling during a drawdown turns a paper loss into a realized one. FINRA cautions against impulsive decisions when markets become volatile[5].

What else do beginners ask?#

Is a drawdown the same as a loss?

Not until you sell. It measures the fall from a peak; the CFTC rule defines draw-down as losses experienced over a specified period[1].

What is maximum drawdown?

The largest peak-to-valley fall in a period; U.S. commodity-pool rules call it the worst peak-to-valley draw-down[1].

How long do drawdowns last?

It varies widely. The S&P 500 regained its 2020 peak within about a year[3]; the Dow took until 1954 to regain its 1929 high[2].

Sources

Numbers in brackets in the text point here. Grade A = primary source (regulator, statistics agency, law or official document).

  1. 1
    17 CFR § 4.10 — Definitions (CFTC, commodity pool operators and trading advisors)eCFR — U.S. Code of Federal Regulations (current) · Grade A
  2. 2
    Stock Market Crash of 1929Federal Reserve History (Federal Reserve System) — Gary Richardson, Alejandro Komai, Michael Gou, Daniel Park (2013) · Grade A
  3. 3
    How COVID-19 Has Impacted Stock Performance by IndustryFederal Reserve Bank of St. Louis (On the Economy) (2021) · Grade A
  4. 4
    Form N-1A (registration form for mutual funds and ETFs), Item 4(b)(2)U.S. Securities and Exchange Commission (current) · Grade A
  5. 5

How we checked this note

Every number, date and rule above links to its source. This note cites 5 sources, 5 of them primary (Grade A). Worked examples were calculated in code, and a second editor compared each figure with its source before publishing. Spotted an error? Tell us — corrections are listed on the note. Read our editorial policy.
